HPI-BFV1D06 Series Vortex Flowmeter (Display-Type, Corrosion-Resistant)
Display-type, corrosion-resistant; Switch signal + 4~20mA + IO-Link multi-output
Key Features
- Digital + 4~2 mA + IO-Link Multi-output
- PP full plastic corrosion-resistant material
- Range 1~120 L/min
- Pressure Rating: 16 bar
- Digital display with real-time traffic monitoring
- Suitable for PV wet processes and industrial cooling
Key Parameters
Output Signal
Digital Input/Output + 4~20mA + IO-Link
Material
PP All-Plastic Anti-Corrosion
Range
1~120 L/min
Voltage Rating
16 bar
Detailed Technical Specifications
| Output Signal | Digital Input/Output + 4~20mA + IO-Link |
| Material | PP All-Plastic Anti-Corrosion |
| Range | 1~120 L/min |
| Voltage Rating | 16 bar |
| Display Mode | Digital LCD Display |
| Operating Temperature | -10~80℃ |
| Medium Temperature | -10~80℃ |
| Ingress Protection Rating | IP67 |
| Supply Voltage | 12-24V DC |
| Response Time | <200ms |
| Accuracy Class | ±3% |
| Repeatability | / |
| Pipe Diameter | DN15-DN50 |
| Installation Method | Flange/Threaded Installation |
| Cable Interface | M20×1.5 |
| Service Life | ≥500 K |
Application Scenarios
Photovoltaic Wet Process
Monitor chemical solution flow in photovoltaic texturing and etching processes
Industrial Cooling
Industrial Cooling System Flow Monitoring and Control
Medication tubing
Flow Detection for Chemical Liquid Transfer Pipelines
Water Treatment
Water Treatment System Flow Monitoring
