HPI-BD Series Gantry Switch
Mechanical/photoelectric sensor for basket positioning in PV/semiconductor cleaning lines
Key Features
- NPN 3-wire / 2-wire selectable
- Mechanical / Photoelectric Sensing Principle
- IP65 protection, resistant to acid and alkali corrosion
- Ultra-long lifespan 1×10⁶ cycles
- Fast response and precise positioning.
- Suitable for automated production lines
Key Parameters
Output Type
NPN 3-wire / 2-wire selectable
Detection Principle
Mechanical / Photoelectric Sensor
Ingress Protection Rating
IP65 Acid & Alkali Resistant
Service Life
1×10⁶ times
Detailed Technical Specifications
| Output Type | NPN 3-wire / 2-wire selectable |
| Detection Principle | Mechanical / Photoelectric Sensor |
| Ingress Protection Rating | IP65 Acid and Alkali Resistant |
| Service Life | 1×10⁶ times |
| Operating Voltage | 12-24V DC |
| Output Current | ≤100 mA |
| Response Frequency | ≤1kHz |
| Detection Distance | / |
| Operating Temperature | -10~80℃ |
| Casing Material | PP/PVDF available; PVDF is the default. |
| Cable Length | Standard 5m |
| Indicator light | LED Status Indicator |
| Installation Method | M8 Threaded Mount |
| Reset Method | Auto-reset |
Application Scenarios
Photovoltaic Industry
Basket Position Detection for PV Cleaning Line
Semiconductor
Semiconductor Cleaning Line Basket Position Detection
Automated production line
Automated Production Line Workpiece Inspection
Electroplating Industry
Electroplating Line Hanger Position Detection
