HPI-P132-F Series Ceramic piezoresistive flat diaphragm pressure sensor
Ceramic piezoresistive sensor element, flush-diaphragm cavity-free anti-clog design
Key Features
- Ceramic Piezoresistive Core
- Accuracy class 0.25%/0.5%/1% FS available
- Flush diaphragm with cavity-free structure to prevent clogging and crystallization
- 316L stainless steel liquid-contact material
- Range: -0.1 MPa to 60 MPa, customizable
- 4-20mA/RS485 Output
Key Parameters
Core Type
ceramic piezoresistive
Accuracy Class
0.25%/0.5%/1% FS
Structure
Flat membrane, cavity-free; anti-clogging and anti-crystallization
Wetted Materials
316L Stainless Steel
Detailed Technical Specifications
| Core Type | Ceramic Piezoresistive |
| Accuracy Class | 0.25%/0.5%/1% FS |
| Structure | Flush diaphragm with no cavity; prevents clogging and crystallization. |
| Wetted Materials | 316L Stainless Steel |
| Range | -0.1MPa~0.1MPa...60MPa (customizable) |
| Output Signal | 4-20mA/RS485 |
| Operating Temperature | -40℃~+90℃ |
| Medium Temperature | -40℃~+90℃ |
| Ingress Protection Rating | IP65 |
| Supply Voltage | 10~3 VDC |
| overload pressure | 150%FS |
| Response Time | <10ms |
| Threaded Interface | G1/2", M20×1.5, Customizable |
| Output Port | 4-20ma |
| Fluids | Viscous media, corrosive liquids |
Application Scenarios
Chemical Industry
Pressure sensing for viscous chemical media
Photovoltaic Industry
Photovoltaic Wet Process Pressure Monitoring
Water Treatment
Water Treatment System Pressure Monitoring
Food Industry
Food Viscous Liquid Pressure Detection
