HPI-P132-F Series Pressure Sensor
Compact or digital display model available; wide range: -1 bar to 600 bar
Key Features
- Compact BPS (no display) or digital BPD (with display) available
- Range: -1 bar to 600 bar, wide range options available
- BPS=4~20mA; BPD=4~20mA+NPN/PNP digital output
- 304 Stainless Steel
- G1/4" External Thread Interface
- Suitable for liquid cooling systems and photovoltaic equipment
Key Parameters
Type
Compact BPS / Digital Display BPD
Range
-1 bar to 600 bar, optional
Output Signal
BPS=4~20mA; BPD=4~20mA+NPN/PNP Digital Output
Material
304 Stainless Steel
Detailed Technical Specifications
| Type | Compact BPS / Digital Display BPD |
| Range | -1 bar to 600 bar, optional |
| Output Signal | BPS=4~20mA; BPD=4~20mA+NPN/PNP digital output |
| Material | 304 Stainless Steel |
| API | G1/4" External Thread |
| Measurement Accuracy | ±0.5%FS |
| overload pressure | 150%FS |
| Response Time | <10ms |
| Ingress Protection Rating | IP65 |
| Supply Voltage | 10-3 VDC |
| Display Mode | BPD-type LCD digital display |
| Operating Temperature | -40℃ ~ +90℃ |
| Medium Temperature | -40~125℃ |
| Process Interface | G1/4" External Thread |
| Standard Model | Threaded Installation |
Application Scenarios
Liquid Cooling System
Liquid Cooling System Pressure Monitoring
Photovoltaic Equipment
Photovoltaic Equipment Pressure Detection
Pneumatic Hydraulic
Pneumatic and Hydraulic System Pressure Monitoring
Water Treatment
Water Treatment System Pressure Monitoring
